The Newland HR33 Marlin AI Bluetooth (Part Number: NLS-HR3300-BT-V2) is a high-performance cordless 2D barcode scanner built for retail sales, warehousing, healthcare desks, and logistics tasks. Powered by Newland's AI-assisted barcode detection and a 1280x800 Megapixel CMOS sensor, it decodes standard 1D product codes, 2D QR codes, Data Matrix, DotCode, Digimarc watermarks, and OCR data—even on reflective, curved, creased, or damaged surfaces.
Equipped with Bluetooth 5.0 wireless technology, it maintains a working distance up to 100 metres in open spaces. The scanner features a latch-release removable 2600 mAh battery supplying over 15 hours of continuous operation, alongside batch memory capable of storing over 16,000 barcodes when working out of range.
Main Benefits
-
AI-Powered Barcode Reading: Employs computer vision technology to detect and decode damaged, creased, or distorted barcodes on curved and reflective items.
-
Long-Range Bluetooth 5.0: Communicates wirelessly with its charging base station up to 100 metres away in open environments.
-
Acuscan Laser Pointer: Features a cross-laser aimer that pinpoints the exact barcode required when multiple labels sit close together.
-
Quick Swap Battery: The 2600 mAh battery includes a latch-release compartment and a two-colour low-battery indicator, giving over 15 hours of continuous use per charge.
-
Digimarc & OCR Support: Decodes Digimarc digital watermarks, DotCode, and travel document OCR data straight out of the box.
-
Advanced Lua Scripting: Allows custom data formatting rules and automated scanning routines using built-in Lua scripting or EasySet setup tools.
-
Rugged Housing & Long Warranty: Rated IP52 against dust and water drips, withstands repeated 1.8-metre drops to concrete, and carries a 5-year manufacturer warranty.
What Comes in the Box?
-
Newland HR33 Marlin AI Bluetooth 2D Scanner Unit
-
Magnetic Charging / Communication Base Station Cradle
-
USB Interface Cable
-
2600 mAh Rechargeable Lithium-ion Battery
-
Quick Start Setup Guide
| Specification |
Details |
| Brand |
Newland |
| Product Series |
HR33 Marlin AI Series |
| Model Name |
HR33 Marlin AI Bluetooth 2D Scanner |
| Manufacturer Part Number (MPN) |
NLS-HR3300-BT-V2 |
| Scanner Type |
Cordless 2D Megapixel Imager |
| Wireless Connection |
Bluetooth 5.0 (up to 100 metres in open space) |
| Optical Sensor |
1280 x 800 Megapixel CMOS |
| Aiming & Illumination |
Red Cross Laser Aimer / White LED Illumination |
| Special Decoding Capabilities |
AI Barcode Detection, Digimarc Watermarks, DotCode, Passport OCR, Damaged Codes |
| Supported Symbologies (1D) |
Code 11, Code 128, Code 39, GS1-128, AIM 128, ISBT 128, Codabar, Code 93, UPC-A, UPC-E, Coupon, GS1 Composite, EAN-13, EAN-8, ISSN, ISBN, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, ITF-6, ITF-14, Standard 2 of 5, China Post 25, MSI-Plessey, Plessey, GS1 DataBar, Code 49, Code 16K |
| Supported Symbologies (2D) |
PDF417, Micro PDF417, QR Code, Micro QR Code, Data Matrix, Aztec, MaxiCode, Chinese Sensible Code, GM Code, Code One, DotCode, Digimarc |
| Depth of Field Range |
35 mm to 535 mm (EAN-13 13mil) | 20 mm to 245 mm (Data Matrix 10mil) |
| Offline Memory Capacity |
≥ 16,384 barcode entries |
| Battery Specs |
2600 mAh Rechargeable & Removable Li-ion (≥ 15 hours operating life) |
| Configuration Tools |
EasySet Utility and Advanced Lua Scripting Support |
| Base Station Interface |
USB-A (KBW, CDC, HID-POS) |
| User Feedback |
Audio Beeper, Visual LED Light, and Vibration Motor |
| Dimensions (L x W x H) |
Scanner: 117.5 mm x 67.5 mm x 144.0 mm | Cradle: 140.0 mm x 90.0 mm x 144.5 mm |
| Weight |
Scanner: 210 g | Cradle: 340.5 g |
| IP Ingress Rating |
IP52 |
| Drop Resistance |
1.8 metres to concrete |
| Operating Temperature |
-20°C to 50°C |
| Warranty |
5-Year Manufacturer Warranty |
